MB8ZK10-220/300-Rotary Vacuum Packaging Machine

Rotary Vacuum Packaging Machine

Product Description

Model	MB8ZK10-220	MB8ZK10-300
Bag size	(W): 100–220 mm (L): 100–300 mm	(W): 170–300 mm (L): 200–400 mm
Bag type	Aluminum foil bags, nylon bags, paper bags and other four-side sealed composite bags
Filling range	100–1500 g	500–3000 g
Packing speed	35–60 (bags/min)	15–35 (bags/min)
Host weight	3000 kg	3500 kg
Host power	7 KW (without vacuum pump)
Drive power	Three-phase five-wire 380V 50HZ
Dimensions	2820 × 1900 × 1850 mm	3200 × 2530 × 1600 mm
Air consumption	≤0.5 m³/min (compressed air is provided by the user)
Cooling water	Cooling water 15℃–20℃, 3 L/min
